All vehicles that come equipped with halogen headlight bulbs can be upgraded to LED conversion. The primary benefit is a substantial improvement in road illumination, leading to enhanced safety during nighttime driving.

We offer three series of LED performance bulbs: T2, X1, and X2. Our LED bulbs are designed to be "plug-n-play" and come with bulb mounting collars that fit into the same socket and mate with the same wiring connectors as your original halogen bulbs. Installing them is easy.

Please note that the X1 Series bulb base is larger and may occupy more space in your headlamp assembly. On the other hand, the T2 Series, with its innovative aluminum fin cooling system, provides better fitment thanks to its heat sink design. For applications with limited space or plastic dust caps, we suggest using the T2 Series.

This guide will walk you through the steps on how to install a LED Conversion Kit.

Step 1: Determine the Bulb Type for Your Headlight or Fog Light

Your car or truck comes with a designated bulb size/type installed at the factory, following a universally recognized standard for identification. This standard is consistent across the automotive industry, assigning a unique code number to each bulb type.

Find the perfect bulbs for your car using our Year/Make/Model Search. As a safety measure, we advise referring to your vehicle's owner's manual to verify the headlight bulb size.

There are two potential results:

1. Single Beam Bulb - the high and low beams use two separate bulbs
2. Dual Beam Bulb - the high and low beams are combined in one bulb

Step 2: Choose the LED Bulbs That Suit Your Needs the Best

To dissipate heat from LED headlight bulbs with standard brightness, specially designed copper and aluminum "heat sinks" are utilized. These heat sink materials can take the form of flexible braided ribbons or rigid fins arranged in a radial pattern. When we refer to "standard brightness," we are describing the level of luminosity produced by most LED headlight bulbs. It is important to note that this brightness is more intense than that of any halogen headlight bulb. LED bulbs with higher output incorporate small cooling fans into the base of the lighting assembly. These fans draw air over the built-in heat sinks and expel it through strategically placed vents. Technological advancements have also resulted in the development of energy-efficient fans that effectively cool the bulbs, providing a lifespan equal to or greater than the bulbs themselves. If you want to learn more about the different features of the 3 Series of LED Bulbs, you can check out the following link: (LINK)

STEP 3: Choose the Required Wire Harness

If you're dealing with CANbus or PWM system-related problems in newer vehicles, you might require an additional harness. Take a look at this straightforward guide to help you choose the right harness for your LED light conversion needs.

Step 4: Find and Remove the Halogen Bulb

Some modern vehicles have limited space under the hood, which means you need to remove the entire headlight assembly just to change a bulb. In some cases, removing the headlight assembly requires unbolting and moving forward the front bumper cover for clearance.

General Steps:

• Before anything else, make sure your vehicle is properly secured. Turn off the engine, remove the keys from the ignition, and engage the parking brake.
• Open the hood and find your headlight bulbs.
• Disconnect the plastic wiring connector from the bulb.
• To remove the bulb, you may need to first remove a metal clip depending on the bulb type. After that, simply twist it counter-clockwise and pull it out.

Pro tip: Keep your halogen bulbs stored in a secure location for future use.

Step 5: Installing the LED Bulb

• Gently insert the LED bulbs into the headlight socket, being cautious not to touch them with your bare fingers.
• Optional: Before connecting the headlight harness, make sure to attach any additional harnesses to the LED bulb drivers.
• Use either double-sided tape or plastic zip ties to secure the LED Drivers and any other applicable harness.
• Optional: Put on dust cover if available.

Caution:

• Take caution to avoid damaging the power wire of the bulb.

• When adjusting the bulb base, take care not to remove the thermal paste as it can have a detrimental effect on heat dissipation.
• Avoid applying excessive force to the center of the fan, as it can harm the fan's bearing.

• For optimal performance, it is recommended to avoid installing the X1 Series Bulb in applications that are exposed to excessive amounts of elements. Additionally, please refrain from using it to convert Fog Lights.

The majority of LED Headlight Conversions are as simple as replacing your stock bulb. Only 10% of the applications require optional steps.

Pro tip: It is important to ensure that the LED driver is kept away from excessive heat, vibration, and moisture to ensure optimal functioning.

STEP 6: Adjust Headlight Aiming

Ensure optimal visibility on the road by powering up your headlights and testing your LED lights. Take a moment to check the aiming of your headlights to avoid blinding other drivers with their brightness. If necessary, adjust the position of the headlights using the headlight alignment screws. For detailed instructions on how to adjust the aiming of your headlights, consult your owner's manual.
